| 11385-100 | Quote |
|---|
Become familiar with the physiology of hypertension by blood pressure observations
- physical assessment
- vital signes
- OSCE
MW7B
Blood Pressure Measurement Trainer ver.2
| Features | 1. Blood pressure values can be digitally controlled at three points-Phases I,IV nd V 2. Realistic auscultation of phase I to V Korotkoff sounds 3. Radial artery pulses synchronized with sound and cuff pressure 4. Deflation rate can be numerically monitored 5. Excessive cuff pressure is warned by beeping 6. Random play mode for self-learning |
|---|---|
| Training skills / Applications | Cuff placement / Manual cuff inflation / Auscultation of Korotkoff sounds / Palpation of radial pulses / BP reading / Cuff deflation |
| Case / Pathology | Nine preset cases: 1.hypotensive / 2.normal / 3.prehypertension / 4.mild hypertension / 5.moderate hypertension / 6.severe hypertension / 7.isolated systolic hypertension / 8.auscultatory gap / 9.absence of Phase V Korotkoff sounds |
| Set includes | 1 arm model / 1 controller / 1 AC adaptor / 1 power cable / 1 aneroid sphygmomanometerunit / 1 instruction manual / 1 carrying bag (no photo) |
| Size (approx.) | W70 x D19 x H17cm / W27.7 x D7.5 x H6.7in |
| Weight (approx.) | 2.65kg/5.84lb |
| Power source | AC100-240V 50/60Hz |
| Power requirements (approx.) | 10W |
| Materials | Soft resin / Latex free |
| Related products |
M55 Physical Assessment Simulator "Physiko"
|
| Normal: default value of Normal/Setting Mode | Pulse rate: 60 per minute S1(K1):120mmHg, S2(K2)110mmHg, S3(K3) 100mmHg, S4(K4) 90mmHg, S5(K5)70mmHG |
| CE certified/CE Certification? | No |
| Update | October 15, 2020 |
